What is Glide anyway?#
Glide is an image loading library developed by people smarter than me.(granted, I’m not very bright)
You can check out the official docs (https://github.com/bumptech/glide) if you are an inquisitive soul but we both know why you are here.
What you will need#
Source code can be found here (although extensive code samples will be provided for easy copy pasta):
CostaFot/android—glide-review Contribute to CostaFot/android—glide-review development by creating an account on GitHub.
Just click File -> New project in Android Studio 3 and include Kotlin support, AndroidX artifacts and an empty activity pre-made.
Press next on everything and let Android Studio write everything for you.
Dependencies#
Go to the build.gradle (Module: app) file and get it looking like this kind of:
apply plugin: 'com.android.application'
apply plugin: 'kotlin-android'
apply plugin: 'kotlin-android-extensions'
// need this plugin to make this work
apply plugin: 'kotlin-kapt'
android {
// your android stuff goes here
}
dependencies {
// auto-generated dependencies
implementation fileTree(dir: 'libs', include: ['*.jar'])
implementation"org.jetbrains.kotlin:kotlin-stdlib-jdk7:$kotlin_version"
implementation 'androidx.appcompat:appcompat:1.1.0-alpha02'
implementation 'androidx.core:core-ktx:1.1.0-alpha04'
implementation 'androidx.constraintlayout:constraintlayout:1.1.3'
testImplementation 'junit:junit:4.12'
androidTestImplementation 'androidx.test:runner:1.1.2-alpha01'
androidTestImplementation 'androidx.test.espresso:espresso-core:3.1.2-alpha01'
// Glide dependencies here
implementation "com.github.bumptech.glide:glide:4.8.0"
kapt "com.github.bumptech.glide:compiler:4.8.0"
}Glide dependencies
You will also need permission to use the internet in the manifest.
<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:dist="http://schemas.android.com/apk/distribution"
package="com.yourpackagenamehere">
<dist:module dist:instant="true" />
<uses-permission android:name="android.permission.INTERNET" />
<application
android:allowBackup="true"
android:icon="@mipmap/ic_launcher"
android:label="@string/app_name"
android:roundIcon="@mipmap/ic_launcher_round"
android:supportsRtl="true"
android:theme="@style/AppTheme">
<activity android:name=".MainActivity">
<intent-filter>
<action android:name="android.intent.action.MAIN" />
<category android:name="android.intent.category.LAUNCHER" />
</intent-filter>
</activity>
</application>
</manifest>manifest
When does the fun stuff start?#
Who said this was going to be fun?
Get a new package created and create a Kotlin class like this:
@GlideModule
class GlideAppModule : AppGlideModule()The Glide module (???)
Run the app as it is. If you don’t you will be left wondering why everything is red later.
Find a nice image or gif url you would like to load into your app.
Gonna go with this one here for the memes (https://media.giphy.com/media/cYxLgjZI5ezI2lrItX/giphy.gif).
On the plus side (or minus? i dunno), it’s quite a big file which will probably help later when we set a progress bar to show while waiting for it to load.
The layout#
We need something very sophisticated to display the image.
This will do:
<?xml version="1.0" encoding="utf-8"?>
<androidx.constraintlayout.widget.ConstraintLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:app="http://schemas.android.com/apk/res-auto"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context=".MainActivity">
<ImageView
android:id="@+id/imageView"
android:layout_width="0dp"
android:layout_height="0dp"
android:layout_marginStart="8dp"
android:layout_marginTop="8dp"
android:layout_marginEnd="8dp"
android:layout_marginBottom="8dp"
app:layout_constraintBottom_toTopOf="@+id/guideline"
app:layout_constraintEnd_toEndOf="parent"
app:layout_constraintStart_toStartOf="parent"
app:layout_constraintTop_toTopOf="parent"
tools:srcCompat="@tools:sample/avatars" />
<androidx.constraintlayout.widget.Guideline
android:id="@+id/guideline"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:orientation="horizontal"
app:layout_constraintGuide_begin="299dp" />
</androidx.constraintlayout.widget.ConstraintLayout>very complicated layout
Still waiting for the exciting bit#
Loading the url can result in an error or take a really long time cause the hamsters powering the servers are asleep.
Try to have a spinner thing when loading and an image bundled in the app that shows on error.
class MainActivity : AppCompatActivity() {
override fun onCreate(savedInstanceState: Bundle?) {
super.onCreate(savedInstanceState)
setContentView(R.layout.activity_main)
// the URL we want to load
val url = "https://media.giphy.com/media/cYxLgjZI5ezI2lrItX/giphy.gif"
val circularProgressDrawable = createSpinner()
loadUrlIntoImageView(url, circularProgressDrawable)
}
/**
* a basic spinner created programmatically
* this is something that you typically stumble upon on Stack Overflow
*/
private fun createSpinner(): CircularProgressDrawable {
val circularProgressDrawable = CircularProgressDrawable(this@MainActivity)
circularProgressDrawable.strokeWidth = 5f
circularProgressDrawable.centerRadius = 30f
circularProgressDrawable.start()
return circularProgressDrawable
}
/**
* The spinner acts as a placeholder while loading the url
* On error will show R.drawable.ic_launcher_foreground
*/
private fun loadUrlIntoImageView(url: String, circularProgressDrawable: CircularProgressDrawable) {
GlideApp.with(this@MainActivity)
.load(url)
.placeholder(circularProgressDrawable)
.error(R.drawable.ic_launcher_foreground)
.into(imageView)
}
}MainActivity.kt
Wew lad#
Give it a run and check what happens. Try a different url as well as an invalid one to test the error image. The Logcat will have more information too!
That’s it for now.
Later.
