Android Shorts 🩳: Testing Toasts with Espresso

On a long enough timeline, every test is a flaky test

Now why would anyone use this?

class ToastMatcher : TypeSafeMatcher<Root?>() {

    override fun describeTo(description: Description?) {
        description?.appendText("is toast")
    }

    override fun matchesSafely(item: Root?): Boolean {
        val type: Int? = item?.getWindowLayoutParams()?.get()?.type
        if (type == WindowManager.LayoutParams.TYPE_TOAST) {
            val windowToken: IBinder = item.getDecorView().getWindowToken()
            val appToken: IBinder = item.getDecorView().getApplicationWindowToken()
            if (windowToken === appToken) { // means this window isn't contained by any other windows.
                return true
            }
        }
        return false
    }

}

ToastMatcher.kt

Toasts cover the UI for a while, preventing other actions and matchers from working.
Time sensitive.
We are in compose world and..
Matchers suck. 🫠

The only good toast is French Toast

Create a generic Toaster interface that will be responsible for all toasts in the app. Install the implementation into the SingletonComponent :

@Module
@InstallIn(SingletonComponent::class)
object ToastModule {
    @Singleton
    @Provides
    fun providesToaster(
        @ApplicationContext context: Context,
    ): Toaster = object : Toaster {
        override fun showToast(text: String) {
            Toast.makeText(context, text, Toast.LENGTH_SHORT).show()
        }
    }
}

interface Toaster {
    fun showToast(text: String)
}

ToastModule.kt

Add the hilt-testing dependency

dependencies {
    // For instrumented tests.
    androidTestImplementation("com.google.dagger:hilt-android-testing:2.44")
}

build.gradle.kts

Time to leverage TestInstallIn.

Override

@Module
@TestInstallIn(
    components = [SingletonComponent::class],
    replaces = [ToastModule::class],
)
object OverrideToastModule {
    @Singleton
    @Provides
    fun providesToaster(): Toaster = FakeToaster
}

object FakeToaster : Toaster {
    val toasts = mutableListOf<String> ()
    override fun showToast(text: String) {
        toasts.add(text)
    }
}

OverrideToastModule.kt

Any action that should have shown a Toast before, will now add an element in a list instead when running UI tests.

In reality

@AndroidEntryPoint
class MainActivity : ComponentActivity() {

    @Inject lateinit var toaster: Toaster

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContent {
            Button(
                onClick = { toaster.showToast("hello") },
                content = {
                    Text(text = "show toast")
                }
            )
        }
    }
}

MainActivity.kt

This will just show a good old Toast when ran normally.

In testing

@HiltAndroidTest
class MainActivityTest {
    @get:Rule(order = 0)
    val hiltRule = HiltAndroidRule(this)
    @get:Rule(order = 1)
    val composeTestRule = createAndroidComposeRule<MainActivity>()

    @Test
    fun check_that_my_toast_was_shown() {
        composeTestRule.apply {
            onNodeWithText("show toast").performClick()
            assertNotNull(FakeToaster.toasts.firstOrNull { it == "hello" })
        }
    }
}

MainActivityTest.kt
